Emboss Energy Saving smt Tactile Switch With Touch Push Keys Button
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250408-05 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-13 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 20000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate ,silicone Or Other Request | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Pitch Of Connect: | 2.54MM Or Others | Adhesive: | 3M467 Adheisve Or Other Reuqest |
| Size: | Custom Design | Printing Method: | Screen Printing,digital Printing |
| Connector Type: | ZIF Connector , Female Or Male Connector | LED Type: | 0805,0603 Or Other |
| Highlight: | Emboss smt Tactile Switch,Energy Saving smt Tactile Switch |
||
Product Description
Emboss Energy Saving smt Tactile Switch With Touch Push Keys Button
Key Features of SMT Tactile Switches
Compact Size: Most SMT tactile switches come in small dimensions, such as 6 x 6 mm or 12 x 12 mm, making them suitable for space-constrained applications.
Actuation Force: These switches are available with different actuation forces, typically ranging from 1.6N to 5N, allowing designers to choose based on the tactile feedback required for their application .
Sealing and Protection: Many SMT tactile switches, like the KSC11 series, offer IP67 sealing, which protects against dust and water, making them ideal for harsh environments . The B3SL model also features a sealed structure that enhances reliability in dusty conditions .
Electrical Specifications: Common specifications include:
- Contact Rating: Up to 50mA at 32V DC
- Contact Resistance: Typically less than 100 milliohms
- Electrical Life: Ranges from 300,000 to 3,000,000 cycles depending on the model.
Mounting and Packaging: SMT tactile switches are usually available in tape and reel packaging, facilitating automated assembly processes.
Applications
SMT tactile switches are used in various applications, including:
- Industrial equipment
- Medical devices
- Consumer electronics
- Gaming consoles
- Avionics and drones.
Examples of SMT Tactile Switches
- KSC11 Series: Known for its high tactile ratio and long lifespan, suitable for demanding applications.
- B3SL Series: Features a middle-stroke design with a crisp feel, ideal for environments requiring high reliability .
- WS-TASV Series: Offers different actuation forces and is designed for high durability, with a lifespan exceeding 500,000 cycles.
Specification:
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
1 Highly versatile for embossing | 1 wide range of the surface finishes and thicknesses | |||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .Leave space for mechanical keys and provide tactile indications | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
How to order:
• Send us the drawing ,spec or photo about your product or fill our quotation information table . Get Latest Quote
• Confirm order details and approved our artwork before sample ,confirm our sample before mass goods and Order PI will be sent
• Arrange the payment, After payment, we will ship send our artwork for your confirm within 3 days before sample ,and sample lead time is 7 business days
As usual .
mass goods :as common ,it is 7-10 business days ,which is based on our produce department schedule and product craft and order quantity
Our Services :
1 Reply your inquiry within 24 working hours
2 Customize design is available ,OEM and ODM are welcome
3 Experienced Staffs answer your all question in professional and fluent English
4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs
5 Good service ,High quality ,test all goods and short lead time supply
Another photo show :
