Customize Smd Tactile Push Button Switch With Two Flex Ribbon Cables Design
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250408-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 32000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Pitch Of Connect: | 1.0MM Or Others | Adhesive: | 3M467 Adheisve Or Others |
| Button Type: | Metal Dome | Connector Type: | Female Connector |
| Circuit Options: | Silver Flex Circuit | Application: | Bergstrom Electrifieo Systems |
| Highlight: | Smd Tactile Push Button Switch,Customize Smd Tactile Push Button Switch |
||
Product Description
Customize Smd Tactile Push Button Switch With Two Flex Ribbon Cables Design
Key Features of SMD Tactile Push Button Switches
-
Compact Size: SMD tactile switches are typically small, allowing for efficient use of space on printed circuit boards (PCBs). Common dimensions include 6mm x 6mm and 12mm x 12mm.
-
Tactile Feedback: These switches provide a noticeable click or tactile response when pressed, which enhances user experience by confirming that the button has been activated.
-
Mounting Type: They are designed for surface mounting, which simplifies the assembly process and reduces the overall height of the device compared to through-hole switches.
-
Variety of Options: There are numerous types available, including different actuation forces, pin configurations, and sizes. For example, you can find switches with varying operating forces ranging from 100gf to 260gf.
-
Assortment Kits: Many suppliers offer assortment kits containing multiple values and types of tactile switches, which can be particularly useful for prototyping and experimentation. For instance, a kit might include 240 pieces with 24 different values.
Where to Buy
- Amazon: A wide selection of tactile push button switches is available, including bulk packs and assorted kits. Prices can range from around $5.39 for smaller packs to $14.99 for larger assortments.
- DigiKey: This distributor offers a variety of SMD tactile switches with detailed specifications, including pricing starting from approximately $0.12 per switch depending on the quantity and type.
- Adafruit: They provide mini soft touch push-button switches that are SMD and designed for stealth applications, available in packs of 10.
Product Descriptions :
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
|
1 Highly versatile for embossing |
1 wide range of the surface finishes and thicknesses |
|||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .Leave space for mechanical keys and provide tactile indications | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
