Grossly Transparent LCD Screen Round Tactile Switch With Metal Dome
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20241031-16 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 35000 +pcs +a Month |
|
Detail Information |
|||
| Overlay Material: | Polyester Or Polycarbonate ,silicone Or Custom Design | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Adhesive: | 3M Adheisve,Sony Or Others | Embossing Shape: | Rim Or Pollow Embosing |
| Total Thickness: | 0.175MM-1.0MM | LCD Options: | Transparent ,Tinted ,Cutout |
| Pitch Of Connector: | 1.0MM ,1.25MM ,2.54MM Or 0.5MM | Connector Options: | ZIF,male Or Female Connector |
| Highlight: | LCD Screen Round Tactile Switch,Grossly Transparent LCD Round Tactile Switch,Metal Dome LCD Round Tactile Switch |
||
Product Description
Gossly Transpent LCD Screen Round Tactile Switch With Metal Dome
Features of Round Tactile Switches
-
Tactile Feedback: They offer a noticeable click or bump when pressed, allowing users to feel that the switch has been activated.
-
Mounting Styles: Available in both through-hole and surface mount configurations, suitable for different PCB designs.
-
Shape and Size: Typically round in design, these switches come in various diameters and heights, making them versatile for different applications.
-
Lifespan: Generally rated for a certain number of cycles (typically in the millions), ensuring longevity in usage.
-
Actuation Force: They come in various actuation forces, allowing designers to choose the appropriate resistance based on user experience requirements.
Disadvantages
- Potential for Wear: Over time, frequent use can lead to wear and reduced tactile feedback.
- Limited Waterproofing: Many round tactile switches are not inherently waterproof, which can be a drawback in certain applications.
Applications
- Consumer Electronics: Used in devices like remote controls, keyboards, and gaming controllers.
- Appliances: Found in microwaves, washing machines, and other home appliances.
- Automotive: Used in dashboards and control panels for cars.
- Medical Devices: Employed in various handheld devices for reliability and ease of use.
Advantages
- User-Friendly: The tactile response gives immediate feedback, enhancing user interaction.
- Compact Design: Their small footprint allows for efficient use of space on PCBs.
- Versatile: Suitable for a wide range of applications and environments.
Product Performance Index
| Environmental | Operating Temperature | -40°C to +80°C (-40°to 176°F) |
| Storage Temperature | -40°C to +85°C (-40°to 185°F) | |
| Humidity | 40°C, 90% to 95% for 240 hours | |
| Vibration | 20G's max. | |
| Mechanical | Actuation Force | Non-tactile 60g to 300g (2oz to 10oz) |
| Tactile 150g to 400g (6oz to 14oz) | ||
| Switch Stroke | Non-tactile 0.1 to 0.5mm | |
| Life Expectancy | Tactile 0.6 to 1.5mm | |
| Non-tactile >5 million actuations | ||
| Tactile >1 million actuations |
Specification:
1)Material---for front or face overlay
Polyester
1.Highly versatile for embossing 2.Highly resistant to chemicals
3.Better durability 4.For internal and external use
Polycarbonate
1.Wide range of surface finishes and thicknesses
2.More cost-effective 3.For internal and external use
2) Embossing--rim embossing pillow embossing dim embpssing
Graphic overlays can be embossed in order to insert domes (tactile), leave space for mechanical keys and provide tactile indications Pedestal embossing
3)Windows ----for display function
1. print colors windows
2.transparent finishes windows
4)Keys/buttons
Tactile keys---with metal dome or poly dome
Non-tactile--silver printing spot
5) Embeded LEDs-
miniature LED, LED colors:white, yellow, orange, green, red, etc.
6)Cable
is an extension of the printed circuit and is used to communicate with your device
7)Types of connector
1.Zero insertion force (ZIF) connector; 2.Female connector; 3.male connector
8) EMI / RFI / ESD Shielding
use an aluminum foil shielding / a clear ITO electrical conductive polyester
9) Adhesive ----mostly used are 3M-double-side glue
10)Backplate---in aluminum, polycarbonate or acrylic
