Free Proof EL 12v Push Button Switch For Industry Equipment
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250408-03 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 28000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Button Type: | Metal Dome Button | Adhesive: | 3M467 Adheisve Or Others |
| Embossing Shape: | Pillow Embosing | Pitch Of Contact: | 1.0MM Or Other Request |
| Highlight: | Industry Equipment Push Button Switch,EL 12v Push Button Switch |
||
Product Description
Free Proof EL 12v Push Button Switch For Industry Equipment
Types of Push Button Switches
- Latching Push Button Switches: These switches maintain their state after being pressed. They are ideal for applications where you want the switch to stay on or off until manually changed.
- Momentary Push Button Switches: These switches only remain active while being pressed. They are often used for functions like starting a device or triggering a temporary action.
Features
- LED Indicators: Many 12V push button switches come with built-in LED indicators, which can provide visual feedback about the switch's status. For example, the CZone push button switch features a blue LED to indicate circuit status.
- Durability: High-quality switches, such as those made from 304 stainless steel, offer excellent durability and are often rated for environmental protection (IP67), making them suitable for harsh conditions.
- Current Rating: Most 12V push button switches have a maximum current rating, typically around 5 amps, which is sufficient for many low-power applications.
Membrane switch Performance Index
|
Product spec :
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
1 Highly versatile for embossing | 1 wide range of the surface finishes and thicknesses | |||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .Leave space for mechanical keys and provide tactile indications | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
About Taida.pdf
Other photo show :
About ShenZhen TaiDa Menbrane switch CO.,LTD
Taida are an OEM professional specializing in designing and manufacturing membrane switch ,graphic overlay and adhesive sticker/labels with with more than 15 years experience in Shenzhen of China which are widely used in industrial,electronics,household appliance,medical equipments.we have more than 500 different customers .and most of our customer come from USA ,EU ,UK ,middle east and other famous country of world wide.Taida can supply different kinds of Membrane switch based on each client's request .
Factory Strength:
Factory Area: Over 2000 Square meters
Employee :＞ 70
R＆D
Continued quality improvement ,professional Tech support and latest design
From our R＆D department for customers’ demand or samples
Manufacturing
Strong productivity and unified producing process to ensure the fastest delivery time.
QC/QA
20% Employee are QC/QA workers ,quality Guaranteed
Dispatch Department
Power dispatch ability to ensure shipping accuracy and speed
Sales ＆ Customers
Overall ,close and long-term service,No matter in saling and after-sales
Many customers show in our company from worldwide
