Anti Scratch Coated Polyester Key Membrane Switch For Medical Equipment
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250417-07 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 13000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Pitch Of Connect: | 0.3MM ,0.5MM，1.0MM，1.25MM，or 2.54MM | Adhesive: | 3M467 3M468 Adheisve Or Others |
| Button Type: | Metal Dome | Led Color: | 0603 0805 Or Other |
| Highlight: | Medical Equipment Polyester Key Membrane Switch,Anti Scratch Polyester Key Membrane Switch,Medical Equipment Key Membrane Switch |
||
Product Description
Anti Scratch Coated Polyester Key Membrane Switch For Medical Equipment
Construction and Functionality
- Design: Membrane switches consist of multiple layers, including a flexible top layer that contains printed graphics and a bottom layer with conductive traces. When a key is pressed, it makes contact with the underlying circuit, registering the input.
- Tactile Feedback: Many membrane switches incorporate metal domes that provide tactile feedback when pressed, enhancing user experience by giving a noticeable response.
- Durability: These switches are designed for high durability, often rated for around 1 million key presses, making them suitable for frequent use.
Advantages
- Low Profile: Membrane switches are slim and lightweight, making them ideal for applications where space is limited.
- Sealing and Maintenance: They are easier to clean and maintain compared to mechanical switches because they have no openings for dust and debris to enter.
- Cost-Effectiveness: Generally, membrane switches are less expensive to produce than mechanical switches due to their simpler construction and integration of components.
Applications
Membrane switches are widely used in various industries, including:
- Consumer Electronics: Such as remote controls and appliances.
- Industrial Equipment: For control panels and machinery.
- Medical Devices: Where hygiene and durability are critical.
Product Descriptions :
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
|
1 Highly versatile for embossing |
1 wide range of the surface finishes and thicknesses |
|||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .Leave space for mechanical keys and provide tactile indications | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
Key benefits of an anti-scratch coated polyester LED membrane button panel:
- Enhanced Durability and Protection: The anti-scratch coating helps maintain the visual appeal and legibility of the panel over extended use.
- Improved Visibility: The integrated LED backlighting enhances button visibility and usability, especially in low-light environments.
- Hygienic and Easy to Clean: The sealed membrane surface can be easily wiped down and disinfected.
- Versatile Design: The customizable nature allows for seamless integration into a wide range of product designs and applications.
This type of input panel is commonly used in various industries, such as:
- Consumer electronics and home appliances
- Medical and laboratory equipment
- Industrial controls and machinery
- Automotive and transportation interfaces
Common membrane keypad structure choose :
Other photo show :
Product Index:
Operating voltage: 35V DC
Operating current: 100mA 1W
Contact resistance: < 100 Ohms
Open circuit resistance: ≥ 10MΩ at 100V
Operating temperature: Flat/Metal dome:-20°c to +80°c
Storage temperature: Flat/Metal dome:-40°cto +80°c
Life expectancy Flat type≥5,000,000 times Tactile type≥1,000,000 times
Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: +/- 20 to 45g
Tactile ratio: FC > 40%
Operating humidity: up to 95% RH
How to order
• Send us the drawing ,spec or photo about your product or fill our quotation information table . Get Latest Quote
• Confirm order details and approved our artwork before sample ,confirm our sample before mass goods and Order PI will be sent
• we will send our artwork for your confirm within 3 days before sample making ,and sample lead time is 4-5 business days As usual .
mass goods :as common ,it is 7-10 business days ,which is based on our produce department schedule and product craft and order quantity
Our Services :
1 Reply your inquiry within 24 working hours
2 Customize design is available ,OEM and ODM are welcome
3 Experienced Staffs answer your all question in professional and fluent English
4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs
5 Good service ,High quality ,test all goods and short lead time supply
6 we can make any shape ,size ,color ,technology such like button ,LED mounted ,sensor mounted ,and so on based on your request
7 Before mass goods ,we will supply the sample for your approved ,before proofing ,we will design the artwork for your confirm first ,both of them are in order to reduce the cost in the mass goods for you
