Polyester LED Printing Pcb Based Membrane Keypad With Pressure Sensive Adhesive
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250328-04 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 30000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate ,silicone Or Other | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Pitch Of Connect: | 2.54MM ,1.0MM Or Other | Adhesive: | 3M467 Adheisve Or Others |
| Button Type: | Poly Dome | Connector Type: | Female Connector |
| Highlight: | Pressure Sensive Adhesive Membrane Keypad,pcb Based Membrane Keypad,LED Printing Membrane Keypad |
||
Product Description
Polyester LED Printing pcb Based Membrane Keypad With Pressure Sensive Adhesive
Key Features of PCB-Based Membrane Keypads
-
Durability and Robustness: PCB-based keypads are known for their durability, making them suitable for various applications, including industrial automation, medical devices, and consumer electronics .
-
Customization Options: Manufacturers like Rangviswa offer extensive customization options, including:
- Customized front overlays with various material finishes (matte, glossy, textured).
- Embossing options for buttons and logos.
- Different plating options for the PCB (gold, tin-lead, nickel).
- Tactile or non-tactile feedback options.
-
Layered Construction: The typical construction of a PCB-based membrane keypad includes several layers:
- Graphic Overlay
- Graphic Adhesive
- Dome Retainer or ESD Mesh
- Spacer Adhesive
- Metal Domes
- PCB (gold or tin plated)
- Back Adhesive .
-
Applications: These keypads are widely used in various industries, including:
- Medical Devices
- Defense and Military Equipment
- Consumer and Household Appliances
- Gaming Controllers
- Industrial Automation Systems
- Measuring Equipment and Digital Meters .
-
Compliance and Safety: Many PCB-based membrane keypads are designed to be ROHS compliant, ensuring they meet environmental safety standards
Specification:
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
|
1 Highly versatile for embossing |
1 wide range of the surface finishes and thicknesses |
|||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press . | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
