Rim Embossing Membrane Keypad Overlay Tact Buttons For Anchor Winch
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250315-02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | communication |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 11000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Pitch Of Connect: | 2.54MM ,1.0MM Or Other | Adhesive: | Lomman Waterproof Adheisve Or Others |
| Circuit Options: | Silver Flex Circuit | Surface Finish: | Velvet Texture |
| Highlight: | Rim Embossing Membrane Keypad Overlay,Tact Buttons Membrane Keypad Overlay,Anchor Winch Membrane Keypad Overlay |
||
Product Description
Rim Embossing Membrane Keypad Overlay Tact Buttons For Anchor Winch
Key Features:
-
Material:
- Typically made from durable materials like polyester or polycarbonate, which offer resistance to wear, moisture, and chemicals.
-
Customization:
- Can be customized with various colors, textures, fonts, and graphics to align with branding or specific user needs.
- Designs can include backlighting options for enhanced visibility in low-light conditions.
-
User Interface:
- Incorporates printed labels, symbols, and icons that indicate the function of each key, making it intuitive for users.
- May include tactile elements (raised buttons) to provide physical feedback when pressed.
-
Protection:
- Protects the underlying electronic components from dust, moisture, and physical damage.
- Seals the keypad, which is essential for applications in harsh environments.
-
Thin Profile:
- Offers a low-profile design, allowing for seamless integration into devices without adding bulk.
Applications:
- Consumer Electronics: Remote controls, washing machines, and microwaves.
- Medical Devices: Equipment where hygiene and usability are critical, such as infusion pumps and diagnostic machines.
- Industrial Equipment: Control panels for machinery and automation systems.
- Automotive: Dashboard controls and infotainment systems.
Advantages:
- Cost-Effective: Generally less expensive than traditional mechanical switch overlays.
- Easy Maintenance: Smooth surface allows for easy cleaning and maintenance.
- Versatile: Suitable for a wide range of applications across various industries.
Descriptions:
| Overlay material ---For front or face overlay | ||||||||
| Polyester | Polycarbonate | |||||||
|
1 Highly versatile for embossing |
1 wide range of the surface finishes and thicknesses |
|||||||
| Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .Leave space for mechanical keys and provide tactile indications | ||||||||
| Pedestal embossing | Rim embossing | Pillow embossing | Dim embossing | |||||
| Windows or LCD --- For display functions | ||||||||
| Printed colors windows such like red ,black and so on | Transparent finishes windows | |||||||
| Keys | ||||||||
| Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds | Non-tactile keys: printed silver spot on the circuit | |||||||
| LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others | ||||||||
| EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs | ||||||||
| Cables --- is extension of circuit and communication with your device | ||||||||
| Screen printing conductive silver cable | Copper plated cable /Polyimide or FPC | PCB cable | ||||||
| Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector | ||||||||
| Shielding --- For protection function | ||||||||
| Gasket seal/Waterproof :protect the conductors against from the humidity and splashes | EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect | |||||||
| Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others | ||||||||
| Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA | ||||||||
| Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL | ||||||||
| Standard Tolerances :+/-0.2MM | ||||||||
About Taida.pdf
Other photo show :
Electrical Properties:
1, operating voltage: ≤ 50VDC
2, working current: ≤ 100mA
3 Contact resistance: 0.5 ~ 5Ω
4 Insulation resistance: ≥ 100MΩ (100VDC)
5, substrate voltage: 2kDVC
6, spring time: ≤ 6ms
7, loop resistance: 60Ω
8, insulation ink voltage: 100VDC
Our Services :
1 Reply your inquiry within 24 working hours
2 Customize design is available ,OEM and ODM are welcome
3 Experienced Staffs answer your all question in professional and fluent English
4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs
5 Good service ,High quality ,test all goods and short lead time supply
6 we can make any shape ,size ,color ,technology such like button ,LED mounted ,sensor mounted ,and so on based on your request
7 Before mass goods ,we will supply the sample for your approved ,before proofing ,we will design the artwork for your confirm first ,both of them are in order to reduce the cost in the mass goods for you
